DEFU Electric Compressors are engineered for modern electric/hybrid vehicles and retrofitted conventional systems. They serve as primary or supplementary cooling units, enabling engine-off operation via direct battery power (12V, 24V, 48V, 60V, 72V, 96V, and 380V) for applications including trucks, buses, campers, and specialized fleets. Core specifications feature 34 m³/rev displacement, R134a refrigerant with POE68 oil, 2000W/3000W cooling capacity at 1500-3000rpm (PWM/CAN adjustable), CAN communication support, ≥3.1 COP efficiency, and a compact 7.5kg design.
Place of Origin: |
China |
Brand Name: |
DEFU/BEDIRPH/MAXYCOL/MAXYNO |
Certification: |
CE/EMC/MSDS |
Minimum Order Quantity: |
10 PCS/SETS |
Price: |
Negotiable |
Delivery Time: |
15-20 business days |
Payment Terms: |
30% of total as front payment, balance before shipment |
Supply Ability: |
10,000 sets per month |
Product Overview
DEFU DC Electric Compressors are specialized components for modern vehicle AC systems, ideal for electric/hybrid vehicles and retrofitted conventional fleets. Operating on direct battery power (12V-380V), they enable engine-off cooling across compact cars, commercial vehicles, and custom applications.
Key Advantages
These units prioritize energy efficiency by eliminating fuel dependency and emissions, while low-noise operation (<74 dB) ensures passenger comfort. Rapid cooling performance adapts seamlessly to extreme temperatures.
Design & Compatibility
Featuring a scroll-type horizontal design, compressors support ±10° mounting flexibility and withstand -10°C to +65°C environments. IP67-rated housings provide dust/moisture resistance, with compatibility for R134a refrigerant and PWM/CAN speed control.
Performance Specifications
Delivering 34 m³/rev displacement and 2000W/3000W cooling capacity at COP ≥3.1, critical specs include 1500-3000rpm speed range, 50A(12V)/90A(24V) max current, and 7.5kg weight. CAN communication enables vehicle system integration.
Customization & Durability
Rigorously tested (500-hour endurance, 30g vibration resistance, 96-hour salt spray), these compressors offer OEM/ODM adaptability with a 6-year design lifespan, complying with GB/T22068-2008 and IEC60335-2-34 standards.
1. Electric & Hybrid Vehicle Integration
Primary climate control in battery-powered EVs and hybrids, utilizing 48V–380V models for engine-independent cooling.
2. Conventional Vehicle Retrofitting:
Upgrade aging AC systems in fuel-powered trucks/buses using 12V/24V compressors without engine modification.
3. Parking Cooling Solutions
Enable "engine-off" cabin cooling in sleeper cabs, ambulances, and fleet vehicles via auxiliary battery power.
4. Specialty Vehicle Adaptation
Custom installations for off-road campers, tractors, and construction machinery .
5. Harsh Environment Operation
Deploy in extreme temperatures (-10°C to +65°C) with IP67-rated dust/moisture resistance.
|
Specification for electric compressors |
|
|
Displacement |
34 m³/rev |
|
Voltage |
12V/24V |
|
Refrigerant |
HFC134a |
|
Refrigerant Oil |
POE68 |
|
Injection Quantity |
120ml |
|
Range of Speed |
1500-3000rpm |
|
Speed Adjustment Mode |
PWM/CAN |
|
Can Communication |
Yes |
|
Rated Refrigerating Capacity |
2000W/3000W |
|
Rated Power |
720W/960W |
|
Performance Parameters |
≥3.1 |
|
Max Current |
50A/90A |
|
Weight |
7.5KG |
1.Engineering & Performance
Multi-Voltage Support: Seamless integration across 12V–380V systems for EVs, hybrids, and retrofits.
High-Efficiency Design: COP ≥3.1 with 30% lower energy consumption than conventional compressors.
Intelligent Control: PWM/CAN speed modulation (1500–3000rpm) for adaptive cooling.
2.Durability & Reliability
Extreme Environment Ready: IP67-rated housingand-10°C to +65°C operation.
Rigorous Validation: 500-hour endurance testing + 30g vibration resistance.
Certified Longevity: 6-year design lifespan (GB/T22068-2008/IEC60335-2-34 compliant).
3.User-Centric Benefits
Whisper-Quiet: <74 dB operation for enhanced cabin comfort.
Space-Optimized: 7.5kg horizontal scroll-type design with ±10° mounting flexibility.
Zero Emissions: Fully electric operation eliminates direct CO₂ output.
4.Sustainability & Customization
Eco-Compliance: R134a refrigerant + POE68 biodegradable oil.
Scalable Solutions: OEM/ODM support for voltage-specific adaptations.
