Truck air conditioner, also known as parking air conditioner, parking cooler, dc air conditioner, and roof air conditioner and backpack air conditioner. It works as backup air conditioning to make the electric AC work powered by battery directly instead of taking power from engine, widely used while parking to save fuel.
The cooling capacity is 7500-9000BTU for 12V, 7500-9000BTU for 24V.
Place of Origin: |
China |
Brand Name: |
DEFU/BEDIRPH/MAXYCOL/MAXYNO |
Model Number: |
S7 |
Certification: |
CE/EMC/MSDS |
Minimum Order Quantity: |
10 PCS/SETS |
Price: |
Negotiable |
Packaging Details: |
Outdoor: 76*49*42cm; 28.5kg |
Delivery Time: |
15-20 business days |
Payment Terms: |
30% of total as front payment, balance before shipment |
Supply Ability: |
10,000 sets per month |
The 12V 24V Truck Cabin Backpack Parking Air Conditioner S7 enhances driver comfort and road safety by providing optimal temperature and humidity control during parking. Operating directly from the vehicle's 12V/24V battery, it eliminates engine idling to significantly reduce fuel costs while preventing engine wear. Its advanced sine-wave scroll compressor running at 3500 RPM delivers rapid cooling performance (2600-3000W/ 8900-10200 BTU/h), efficiently distributing air through a large copper evaporator coil with automatic swing outlets. Pre-filled with eco-friendly HFC134a refrigerant and featuring smart low-voltage cutoff protection, the system safeguards battery charge to ensure reliable engine restarts.
Designed for practical operation across 18-55°C environments, the unit maintains whisper-quiet performance below 30-45 dB and incorporates a PM2.5 filtration system to remove dust and pollutants from cabin air. Simple installation in standard roof openings takes under an hour using included panels, seals, and hardware. Built with corrosion-resistant copper-aluminum components and certified to CE/EMC/MSDS standards, this versatile solution serves trucks, vans, RVs, and small buses. Remote control allows precise temperature adjustments between 15-30°C from anywhere in the vehicle, completing its user-focused design.
Long-haul trucks : Sleeper cabin cooling during rest stops without engine idling.
RVs and campers : Off-grid climate control for overnight parking.
Commercial vans : Driver safety compliance during deliveries/breaks.
Tractors/agricultural vehicles : Cabin temperature management in extreme fieldwork conditions.
Small buses : Passenger comfort during layovers or intercity stops.
|
12V 24V Truck Cabin Backpack Parking Air Conditioner S7 |
||
|
SNA-S7 |
||
|
Rated Voltage |
12V |
24V |
|
Current |
50-80A |
35-50A |
|
Rated Power |
200-800W |
200-800W |
|
Rated Cooling Capacity |
7500-9000BTU |
7500-9000BTU |
|
Noise level |
30-45dB |
|
|
Performance Coefficient |
≥2.5 |
|
|
Air flow |
480-700 mc/h |
|
|
Refrigerant |
R134a,440g±20g Prefilled,with copper locked |
|
|
Compressor |
Sine WaveScroll Compressor |
|
|
Cold air outlets |
Automatic swing blowing |
|
|
Condenser size |
Aluminum, 400*350mm |
|
|
Evaporator size |
Brushless Copper,668*331*191mm |
|
|
Outdoor/ Indoor size |
750*370*200mm / 668*191*331mm |
|
|
Package |
Outdoor: 76*49*42cm; 28.5kg; |
|
1.Advanced Scroll Compressor Technology:
Fourth-generation sine-wave compressor delivers superior cooling efficiency and energy savings, engineered for silent operation and extreme-condition reliability.
2.Intelligent Battery Protection:
Patented voltage management automatically safeguards battery health and guarantees engine restart capability without manual monitoring.
3.Transformative Fuel Savings:
Eliminates engine idling completely, enabling significant long-term cost reductions while extending engine lifespan.
4.Industry-Exclusive Air Purification:
Integrated PM2.5 filtration system removes airborne contaminants for healthier cabin environments, especially critical in urban settings.
5.Military-Grade Durability:
Corrosion-resistant copper-aluminum construction withstands harsh coastal, humid, and high-salt environments where competitors fail.
