12V/24V DC Full Brush-less Parking Air Conditioner with Full brush-less Motor & Scroll Compressor-DRSS

1. High-Stability Scroll Compressor
Equipped with professional scroll compressor, with adjustable rotating speed of 1000–3500rpm. Stepless speed regulation adapts to different load demands. The compression structure runs with low vibration and high stability, supporting long-term continuous operation and effectively reducing operating failure rate.

2. Full brush-less Fan Motor System
Both condenser fan and evaporator fan adopt brush-less motors. Matched with evaporator fan design, the system features low heat generation, low loss and long service life. Compared with brushed motors, it reduces daily maintenance frequency and ensures stable air output in long-hour working state.

3. Copper Evaporator & Aluminum Condenser
Adopts aluminum condenser and copper evaporator hybrid heat exchange structure. Copper evaporator provides high thermal conductivity and high-temperature resistance for efficient heat dissipation. Aluminum condenser features light weight and fast heat exchange, balancing structural durability and operating efficiency.

4. Customizable Heating Function
Support optional four-way valve customization. The upgraded unit can realize independent heating function on the basis of cooling, adapting to low-temperature environment requirements and achieving all-year-round vehicle temperature adjustment.

1. Graded Power & Cooling Capacity
voltage matching with precise parameter calibration. 12V version: rated power 200–750W, cooling capacity 1800–2000W. 24V version: rated power 200–850W, cooling capacity 2000–3000W. Low power consumption corresponds to high cooling output, reducing battery load and supporting long-time stable operation.

2. High Air Volume & Fast Heat Circulation
The air volume ranges from 240–450 m³/h. Large air volume accelerates internal cab air circulation, realizes fast cooling and uniform temperature distribution, and eliminates local temperature difference in the vehicle.

3. Low Noise Stable Operation
Optimized brush-less motor operation and scroll compression structure control the overall operating noise at 50–62dB. It reduces mechanical vibration and wind noise during operation, meeting the quiet use demand of vehicle parking rest.

1.Sleeper trucks for long trips
2.Delivery vans for transit stops
3.RVs for outdoor travel
4.Engineering equipment for field work

5.Agricultural machines for farm use
